Bay & Bow Windows, Jamestown, NC
Bay & Bow windows will open up your room and project light!
We can help you replace the bay and bow windows in your home.
Bay windows typically consist of three separate window panels that are arranged at a 45-degree or 30-degree angle, with the center window being larger than the other two side windows. The side windows can usually open, while the center window remains fixed in place. If you want to establish a sense of openness and light in a space, while providing extra storage or seating space, a bay window is a good option.
Comparatively, bow windows are made from four or more windows arranged in a curved shape, which provides a gentler projection than bay windows. Bow windows usually have operable windows on both ends with a mix of fixed and operable windows near the center. Bay windows often provide a more elegant and dramatic look than bay windows, but they also require more structural support.
At Window Depot of the Triad, we often recommend bay & bow windows because they provide ample natural light and ventilation, as well as architectural interest to any home. We often recommend these windows for dining rooms, living rooms, and bedrooms to create an interesting focal point and a beautiful design aesthetic to the space.
We would love to talk to you more about bay & bow windows and how they can enhance your home in the Jamestown, North Carolina area. Contact us today to set up a consultation!
Luxury meets affordability with our beautiful Bay replacement windows. Installing a Bay or Bow window in your home adds timeless elegance, as well as boosting curb appeal. Our bay and bow windows are sure to make your neighbors swoon!
Bay windows are made of three panels that are joined together. The window in the middle is parallel with the side of the building on which it is installed, and the other two are angled to meet at the edges of the center window. Bow windows are constructed with three or more panels and take on a curved shape. The end window panels are usually operable.
Our bay and bow windows are created using double-hung or casement windows for the end windows and putting a large picture window in the center. Our bay and bow windows are custom-made to fit the precise dimensions of your home.
Our Signature Series Dimensional Projection Windows features multiple configurations and are available in virtually any size. Additional standard features include foam-filled structural mullions and an all-thread through rod, which locks together the head and seat boards.
BENEFITS:
- Strength, Quality & Performance
- Easy to Open and Close
- Easy cleaning from inside your home
- 25% better at keeping your home draft-free
- Glazing options for every application & budget
- 140% stronger than metal
- Ventilation with limited sash opening
- Improved energy-efficiency & performance
FEATURES:
- Heavy-duty, reinforced main frame
- Thermally-efficient vinyl sill in choice of white, tan and aluminum-look laminate.
- Superior non-corrosive roller system made from technologically-advanced composite material
- Custom-made to perfectly fit your home
- Heavy-duty, easy gliding screen, which snaps into a dual-track system when installed and stays in place
- Full-length interlock system for door panels at the meeting rail
- 5¼” jamb thickness, ideal for replacement applications
- Available with White, Tan, Nickel, Brass, Antique Brass, Oil Rubbed Bronze or Dark Bronze hardware
- Standard 5′, 6′ and 8′ two-panel and 9′ and 12′ three-panel doors
At Window Depot of the Triad, we install bay & bow windows for customers in Piedmont Triad, Greensboro, Winston-Salem, Jamestown, Irving Park, Summerfield, Oak Ridge, Kernersville, and High Point, North Carolina.
%
Increased Energy Efficiency
%
Average Price Savings
%
Increase Condensation Resistance
Window Depot USA is proud to partner with ProVia, custom manufacturer of our Triple Pane Windows & Entry Doors.
Click to learn more about our ProVia Partnership.
You can also download our Endure brochure by clicking on the brochure image, or by clicking here.
DECORATIVE OPTIONS
CHOOSE YOUR COLORS
Endure™ windows are available in appealing woodgrain interior colors, along with four popular exterior vinyl colors. Remember, each room in your house is unique, so your windows should be too. Choose interior colors to complement each room’s style.
Upgrade to a Painted Exterior
15-year warranty on paint finish
Standard with FlexScreen®
Allow for additional lead time
Select Your Hardware Finishes
ENERGY SAVING PACKAGES
PLATINUM PACKAGE
For homeowners looking for the absolute maximum in energy efficiency.
- U Factor = 0.17
- Energystar MOST EFFICIENT
- Triple Glazed
- 2 Low E Glazing Surface Coatings
- Krypton Insulating Gas-Filled In Two Chambers
- Warm-EdgeSpacer Technology
- SHGC = 0.23
- VLT = 0.37
- Air Infiltration = 0.05
For more information on this extraordinary insulating package, please contact your local Window Depot.
GOLD PACKAGE
- U-FACTOR of 0.19
- Energystar MOST EFFICIENT Awarded
- TRIPLE Pane Glazing Technology
- Dual Surface Low E
- Argon Gas Fill
- Solar Heat Gain Coefficient = 0.23
- Visible Light Transmittance = 0.37
- Air Infiltration = 0.05
This combination of price, energy performance, and overall value cannot be matched!
SILVER plus PACKAGE
- Double-Stacked Low-E Glass
- Argon Insulating Gas-Filled
- U Factor = 0.27
- SHGC = 0.27
- VLT = 0.50
- Air Infiltration = 0.05
ENERGY SAVING PACKAGES
PLATINUM PACKAGE
For homeowners looking for the absolute maximum in energy efficiency.
- U Factor = 0.17
- Energystar MOST EFFICIENT
- Triple Glazed
- 2 Low E Glazing Surface Coatings
- Krypton Insulating Gas-Filled In Two Chambers
- Warm-EdgeSpacer Technology
- SHGC = 0.23
- VLT = 0.37
- Air Infiltration = 0.05
For more information on this extraordinary insulating package, please contact your local Window Depot.
GOLD PACKAGE
Our Signature Package* With the GOLD package from Window Depot USA, your windows come with the following energy saving features:
- U-FACTOR of 0.19
- Energystar MOST EFFICIENT Awarded
- TRIPLE Pane Glazing Technology
- Dual Surface Low E
- Argon Gas Fill
- Solar Heat Gain Coefficient = 0.23
- Visible Light Transmittance = 0.37
- Air Infiltration = 0.05
This combination of price, energy performance, and overall value cannot be matched!
SILVER plus PACKAGE
Chock full of features, many of which our competitors consider “upgrades”, the Silver PLUS package from Window Depot USA also gives you certified EnergyStar performance.
- Double-Stacked Low-E Glass
- Argon Insulating Gas-Filled
- U Factor = 0.27
- SHGC = 0.27
- VLT = 0.50
- Air Infiltration = 0.05
Request your Free Estimate
PERFORMANCE FEATURES
FIBERGLASS REINFORCEMENT
As the next-generation of thermal reinforcement for the industry, Innergy is able to deliver a quantum Leap above aluminum in how windows perform.
- Better Thermal Performance
Up to 700 times better than aluminum in material comparisons.
- Better Thermal Break
Impervious to cold or heat.
- Better Protection Against Condensation
Helps prevent staining that can occur with metal reinforcements.
- Better Impact Testing
Resistance to impact versus other reinforcement products.
- Better Flexibility
Will not permanently set when impacted.
Advanced Weatherstripping
Neopor Foam
FIBERGLASS REINFORCEMENT
Innergy is the innovative, energy-efficient alternative to aluminum, with added insulating properties making it 700 times better.
As the next-generation of thermal reinforcement for the industry, Innergy is able to deliver a quantum Leap above aluminum in how windows perform.
- Better Thermal Performance
Up to 700 times better than aluminum in material comparisons.
- Better Thermal Break
Impervious to cold or heat.
- Better Protection Against Condensation
Helps prevent staining that can occur with metal reinforcements.
- Better Impact Testing
Resistance to impact versus other reinforcement products.
- Better Flexibility
Will not permanently set when impacted.
Advanced Weatherstripping
Bulb seals are seamless closed-cell compression seals that prevent water from penetrating the foam cell structure. Its extruded skin provides a unique UV resistant barrier with design features that enhance the weatherstrip’s sealing performance.
Seal woven and extruded pile weatherstripping with fin provides a very effective barrier against air, water, dust, and noise, sealing against even and uneven surfaces with resistance to abrasion.
Neopor Foam
Neopor gives maximum efficiency and sustainability in building products. It is comprised of many small pockets of air within a polymer matrix containing graphite. The graphite reflects radiant heat energy like a mirror, increasing the material’s resistance to the flow of heat, or R-value. Neopor is unique because it increases R-Value as the temperature outside drops.
Why Choose Vinyl?
Our windows are constructed of SunShield® vinyl, made with a compound proven to perform better than alternative building materials. Vinyl ensures long-lasting color retention and low maintenance, plus the added confidence of a warranty against rotting, cracking, pitting, corroding, and peeling. The vinyl is resistant to rot, insect and microbial damage, never requires painting, and is easy to clean.
- Low Maintenance – Vinyl windows are the low-maintenance choice for residential use.
- Superior Weatherability – SunShield vinyl is uniquely formulated to withstand the harsh effects of weather, UV light, and southern exposure.
- Color Retention – Pharmaceutical-grade compounding and blending systems provide consistency, so you can rely on superior color and weatherability.
- Designed to Perform – Industry partnerships and ongoing research into new technologies ensure the vinyl compound exceeds industry standards, outperforms the competition and works together to offer best-in-class technology.
- Uncompromising Quality and Performance Testing – SunShield vinyl meets or exceeds the standards for strength and color retention established by the American Architectural Manufacturer’s Association (AAMA).
